Next generation heavy duty synthetic

Name: Duraview™
Brand: Cyclone Screening
SKU: 30122736
Availability: OutOfStock

Duraview™

Cyclone Duraview™ delivers extra strength and durability, over most other traditional flyscreens.

This tough, heavy-gauge polyester mesh is engineered to withstand continued exposure to severe weather conditions as well as being more resistant to everyday wear and tear.

Key Benefits

4X stronger than Fibreglass
100% VOC-free: No chemical smell
High thermal resistance -25°C to 80°C
Self-cleaning technology keeps screen cleaner for longer
Thermo-Bonded: No warped strands

Download Tech Spec

Protection

Visibility

Airflow

Strength

Applications

Window Rating

Door Rating

Ideal for server sea-shore corrosion zones

Surf beach shoreline regions with very high salt deposition.

This screen can be used as part of a complete window system to satisfy building code in relation to fall protection.

Clauses 3.9.2.5 and D2.24 of the Building Code of Australia detail the situations in which open-able windows require fall prevention measures and the requirement that windows in these instances must meet. The test standard AS5203:2016 -Protection of Openable Window / Fall Prevention Test outlines a window opening will not permit a 125mm sphere to pass through it and resist a horizontal outward force of 250N.

Ideal for retractable systems

For use on windows and doors. verandahs, patios.

Technical Specifications

Download Tech Spec

Material:: Bicomponent Monofilament

Weight:: 145gsm

Openness:: 58%

Aperture:: 1.21 x 1.21mm

Strand Diameter:: 0.38mm

Tensile Strength:: 400(N/20mm)

Elongation:: 15%

Available Sizes

Retail Sizes

Find a retailer

Part Number	Width	Length
30122729	910mm	2m
30122736	910mm	6m
30122743	1220mm	2m
30122750	1220mm	6m

Commercial Sizes

Fabricator Enquiry

Part Number	Width	Length
30123184	910mm	30m
30123191	1220mm	30m
